Industrial hot air oven
View Large
Product Name : Industrial hot air oven
Product Origin : China
Product Category : Temperature & humidity gauges
More Products : Click here!
Contact Details : Dongguan Yuanyao Electronics Technology Co., Ltd
Product Code : YPO-600
Product Details

Introduction of Industrial hot air oven


This oven adopts computerized electronic digital control, precise & reliable.The packing of box insulation is moulded by silicone, high-temperature enduring & never aged attache with observation view window, easy to be used.Heating is by compusory circulation ventilation, temperature raising is fast and spread even.PID control system, double sided overheating protection, safe & reliable. Easy to set temperature, easy to operate.Attached two sets of movable disd to be adjusted high and low at your disposal.


Technical specifications of Industrial hot air oven:




























































































YPO-072 YPO-270 YPO-480 YPO-600 YPO-720
450×400×400 600×900×500 800×1000×600 1000×1000×600 1200×1000×600
870×1200×550 1050×1650×740 1200×1700×840 1400×1750×840 1750×1750×840
Room Temp.+10°C~+200°C(300°C)
Ferformance Temp.&Humi,Constancy ±0.3°C
Temp.&Humi,Constancy ±0.1°C AT 200°C ±1.5%AT300°C
Indication Resolution 0.1°C/1°C
Heat-up Time( min.) Approx.60min.
Material Exterior Iron Sheet+Baked Enamel
Interior SUS#304 stainless steel piate
Insulation Fiberglass Wool
SYSTEMS Cirulation Circle Fen
Heating Chrome Steel Strip Wire Heater
Controller Electric Digital Control+S.S.R.
Single-Wing Double-Wing
Environmental Control Indicator Lights,
Experiment Separation Shelves(2 pcs).
Overheating Prevention Circuit breaker,
Control System,Breakdown Indicator Light.
AC 1Ψ 220V  3Ψ 380V 60/50Hz





Main features of Industrial hot air oven:


1. Adopt precise and reliable control way of computerized electronic digital controller.


2. The door sealing uses silicone, which endures high temperation. View window attached.


3. The centrigugal fan provides greater cyclic airflow to avoid dead corner in the chamber so as to obtain uniform distribution of temperature.




Besides the Industrial hot air oven , We are also manufacturing the following equipments:

Temperature & humidity Chamber, Temperature & humidity Control Host, Air Thermal Shock Tester, Liquid Thermal Shock Tester, Salt Spray Tester, Walk-in environmental Testing Room, Temperature & humidity & Vibration Combined Testing Chamber, Aging Oven Tester, Rain/Spray Testing Chamber, Burn-in testing equipment, Dust Tester, Steam Aging Tester, Electromagnetic High Frequency Vibration Tester, Tensile Tester, Drop Tester, Precision Oven Tester, etc.


Customization of inner chamber size and other specification is available upon request.

Product Attachment
File Name : 5.合作客户.jpg
File Size : 125.17KB     File Type : image/pjpeg
Industrial hot air oven
