Product Name : | QFJ Series of Auto Slitting Machines |
| Product Origin : | China | |
| Product Category : | Packaging machines | |
| More Products : | Click here! | |
| Contact Details : | Ruian Jingsai Printing Machine Co., Ltd. | |
| Product Code : | QFJ Series |
Product Details
Name: QFJ Series Auto Slitting Machines
Max speed of slitting and rewinding: 160 meters/min
APPLICATION:
Machines in this series are suitable for stripping of reel-shape materials such as cellophane paper, Aluminum-platedfilm, foil, BOPP, PVC, PET, aluminum foil, and paper.
FEATURE:
1. They are upright stripping machines.
2. Independent micro computer control screen, making easy operation.
3. Magnetic powder control for tension of reeling and unreeling.
4. Auto metering with material running, auto photoelectric error correction for unreeling.
5. Equipped with side waste scrap air-blowing sending or reeling devices.
6. Dual-air swelling shaft reeling, smooth and level end face splitting.
7. Disc knife accessories must be selected for slitting aluminum foil and paper.
wzprint2(AT)gmail(DOT)com
Technical Variables:
Model:QFJ-700/QFJ-1100/QFJ-1300
Diameter of Width:700mm/1100mm/1300mm
Unwinding Diameter:600mm/600mm/600mm
Rewinding Diameter:400mm/ 400mm/400mm
Slitting and rewinding speed Specification:20-700mm/20-110mm/20-1300mm
Slitting and rewinding speed: 10-160m/min/10-160m/min/10-160m/min
Error correction accuracy:±2mm/±2mm/±2mm
Total Power:3kw/4kw/5kw
Net weight of machine: 1900kg/2100kg/2300kg
Overall dimensions(L*W*H):1200*1900*1270mm/1200*2300*1370mm/1200*2500*1370mm
