Desktop epoxy dispensing robot
View Large
Product Name : Desktop epoxy dispensing robot
Product Origin : China
Product Category : Scientific/laboratory measuring & testing instruments
More Products : Click here!
Contact Details : Dongguan Yuanyao Electronics Technology Co., Ltd
Product Code : PY-330D
Product Details

Main features of Desktop epoxy dispensing robot:



1. Keyboard control in English version, easy operation and maintenance.



2. Major functions: Drawing point, line, surface, arc, circle, irregular curve continuous complement and triaxial  linkage.



3. Equipped with pro. software that has area display, translation rotating operation functions.



4. Be able to set size of gluing area, speed of gluing, dispensing time, stopping glue time. Stable glue exudation without glue leaking and dripping.



5. According to the production process, work platform can be installed with positioning PIN, glue guns, baseboard heating temperature controlling device.



6. General applications: Widely applied to fluid dispensing, e. G.: UV glue, AB glue, EPOXY(black glue), white glue, EMI conductive glue, silicon, epoxy resin, instant glue, silver glue, red glue, paste, thermal grease, welding control paste, transparent paint, screw fixative...



7. Applicable objects: Mobile phones, computer case, CD-ROM driver, printer, ink folder, PCB board, LCD, LED, DVD, digital camera, switches, connectors, relays, radiators, semiconductors, clocks, toys and medical appparutus.





General specifications of Desktop epoxy dispensing robot:






























































Model PY-220D PY-330D PY-440D PY-550D
Work Area 200*200*100mm 300*300*100mm 400*400*100mm 500*500*100mm
Travel speed 500mm/sec
Resolution 0.02mm
Repeatability ±0.02mm
Operator system LCD panel/keyboard
Drive Mode Micro stepping motor/belt
Power AC220V 50-60Hz 0.8KW
Size 380*370*500mm 480*500*600mm 580*600*600mm 640*700*720mm
Weight 20KG 30KG 40KG 50KG
Work Condition Temperature:0-40°C, Moisture:20-90%RH



Besides the Desktop epoxy dispensing robot, we are also manufacturing:

Temperature & humidity test Chamber, Temperature & humidity Control Host, Walk In environmental Test Room, Precision hot air Oven, Salt Spray Tester, dustproof hot Oven, Rain/Spray Test Chamber, Dust Tester,Glue dispensing machine, Air Thermal Shock Tester, Liquid Thermal Shock Tester, Temperature humidity & Vibration Combined Testing Chamber, Burn-in testing equipment, Steam Aging Tester, Electromagnetic High Frequency Vibration Tester, Tensile Tester, Drop Tester, etc.


Other styles with different configurations are available upon request, welcome to enquire and purchase!
