Introduction



This oil filling machine is controlled by gowe digital and full automatic filling machine. It is measured in by Flowmeter. The speed of filling differs as per the volume to be filled as the machine is equipped with bottom-up fill assembly and adjustable volume control.



Application



This series of oil filling machine are widely used in filling a variety of oils and viscous liquids, such as peanut oil, blend oil, rapeseed oil and other edible oil filling.



Parameters of Oil Filling Machine



Model                               ZLDG-8



Filling head number   8



Filling speed                  1000-2000 (B / h)



Filling capacity            1-6 liters /0.1-1 liters (can be customized according to user requirements); ( 1-6L/ 0.1-1L/ >6L /  1-20L, etc.)



Filling accuracy           less than or equal to 0.5%FS.



Power source                220/380V



Air pressure                   0.5-1.0Mpa



Type                                  Full automatic Oil Filling Machine



Features of Oil Filling Machine



The adjustment in dosage is convenience and quick



Filling capacity: 1-6L/ 0.1-1L/ >6L /  1-20L, etc



The volume only need to be set on the touchscreen directly



We have added an automatic temperature-compensated system.



Flow meter type oil filling machine is adopting rotary encoder so that is more accurate.



Filling speed: instead of the traditional power delivery --  pressure artesian flow, our machine adopting frequency converter to adjust the speed of filling,the efficiency highly raised.



Filling speed of digital control oil filling machine can be arbitrarily adjusted on panel.



The adjustment of filling accuracy, promoted by our company, the weight of filling can be set on the touchscreen.The equipment carries on automatic conpensation system when error occurs.



Each filling head’s speed of gowe digital control oil filling machine can be set on touchscreen.



Conveyor belt be adjusted by frequency conversion



We manufacture these machines using quality measures as per standards. It is efficiently equipped with adjustable volume control and bottom-up filling assembly and filling speed differs with volume. This filling machine work on continous volumetric principle through PLC controlled by Flow meter



Standard Export Packing for Oil Filling Machine



A.Cover by PVC film + fumigated wooden case;



B.Wooden case suitable for long distance ocean shipping.



Package Site of Oil Filling Machine Filling Line / Oil Filling Equipment



Our Services



Dongtai has a highly sophisticated technical talent, has a high- quality team, can in a timely manner to provide customers with comprehensive after-sale service.



No damage to human factors, all products one year warranty, life-long maintenance.
