Product Name : | JSZD-400-A three-side (middle sealing)bag making machine |
| Product Origin : | China | |
| Product Category : | Packaging machines | |
| More Products : | Click here! | |
| Contact Details : | Ruian Jingsai Printing Machine Co., Ltd. | |
| Product Code : | JSZD-A series |
Product Details
Name:JSZD-A Series three-side (middle sealing)multi-function bag making machine
Max. Working Speed:30meters/min
Application:
With such characteristics as reasonable structure, easy operation and high automatic, this machine is suitable for producing various plastic-plastic, paper-plastic, paper-paper laminated material and it is a kind of ideal bag-making equipment for producing three-side sealing. five-side sealing standing bags.
Performance and Characteristics:
1. The whole machine adopt LCD screen real-time display.
2. All the parameters adopt LCD screen real-time display. The pouch-making speed, pouch-making length, temperature, counting and conveying of finished products, etc. can be preset via touch screen.
3. EPC automatic deviation-rectifying, double photocell tracking.
4. The temperature can be centrally controlled by computer.
5. Automatic blowing and collecting of rim charge, electrostatic elimination.
6. The whole machine has centralized fuel filling system for every lubricating point.
7. The main machine adopts imported frequency control of motor speed.
wzprint2(AT)gmail(DOT)com
Technical Variables:
Type:JSZD-400 JSZD-500
Max. Diameter of Roll Materia:600mm 600mm
Max. Width of Roll Material:800mm 1000mm
Pouch-making Width:70-400mm 70-500mm
Pouch-making Length:70-300mm(option: skip material feeding) 70-300mm(option: skip material feeding)
Capacity:40-120pcs/min 40-120pcs/min
Total Power:23kw 25kw
Weight of Machine:3500kg 4000kg
Overall Dimension:10500*1700*1800mm 10500*1900*1900mm
