Flush Mount Bullet Backup Camera
Feature:
1.)Waterproof and weather resistant housing for outdoor use
2.)Embedded type
3.)Fixed spring adds convenience and reliability for installation
4.)Waterproof IP67~68,anti-fog,anti-shock
5.)Other functions:Parking line,Mirror image and original image(optional)
Specification:
Model:TOP-313M
1.)Image Device:Micron CMOS low illumination sensor (OV-7950)
2.)TV System:NTSC
3.)Effective Pixels:NTSC:656H*492V
4.)Sensing Area:3.584mm(H)*2.688(V)mm
5.)Scanning System:2:1Interlace
6.)Sync.System:Internal
7.)Horizontal Definition:420 TV Lines
8.)Minimum Illumination:0.2 Lux/F1.2
9.)Video Output:1.0Vp-p 75 ohm
10.)Gamma Consumption:0.45
11.)AGC:ON
12.)S/N Ratio:Better than 48dB
13.)White Balance:Auto
14.)Electronic Shutter:1/50~1/10000 sec
15.)BLC:Auto
16.)Waterproof:IP67-IP68
17.)Current Consumption:Max.65mA
18.)Power Supply:DC12V
19.)Operating temperature:from -20deg to +75deg (relative humidity 95% max)
20.)Storage temperature:from -40deg to +85deg(relative humidity 95% max)
21.)Lens:1.7 mm
22.)Lens Angle:120deg(diagonal)
23.)Weight:0.22kg
24.)Other functions:Parking line
