Product Details
Item Full Color
Model PH6
Encapsulation SMD
Pixel pitch (L×W)
mm 6
Pixel density dots/m2 27,777
Module resolution (L×W)
dots 32×16
Size of module (L×W)
mm 192×96
Max.Power consumption W/m2 1,950
Control mode Video synchronization/Asynchronism
Weight Kg/m2 40
Brightness cd/m2 ≥2,000
Grey scale ≥4,096 grades
Colors ≥68.7Billion
Brightness adjustment 256 grade adjustable
Driving mode 1/8 scan
Refreshing frequency ≥180Hz
Communication distance Cat. 5 communication cable not over 120 meters(without relay), optical fiber transmission 10,000 meters
Power supply AC220V/50Hz
AC110V/60Hz
Display mode 640×480
800×600
1024×768
