Semi-Auto Gable Top Beverage Filling Machines (BW-1000)
View Large
Product Name : Semi-Auto Gable Top Beverage Filling Machines (BW-1000)
Product Origin : China
Product Category : Liquid Filling Machine
More Products : Click here!
Contact Details : Shenyang Beiya Beverage Machinery Co.,Ltd
Product Code : BW-1000
Product Details

 BW-1000 type Semi-Auto Gable Top Beverage Filling Machines consist of three separate machines: Carton forming machine, capping machine and filling machine. The entire machine is made of 304 food-grade stainless steel. The surface is special processed to be beautiful and durable in use.




1. Work flow:

1) Carton Forming part: Cardboard -- Put the cardboard onto the mandrel (manually) -- Bottom heating -- Bottom sealing -- Top open carton

2) Capping part: Put the cap into the carton's capping hole (manually) -- Ultrasonic welding -- Top Open Carton with Cap (optional)

3) Filling part: Put the carton onto the conveyor (manually) -- Top preforming -- Filling -- Top heating -- Top sealing -- Date printing --Finished product



The operation of the filling machine is automatically controlled by computer program, and others are controlled by electric apparatus. The whole progress is controlled by PLC, needs 3 persons to operate.



2. Suitable for filling:



Milk, yogurt, cream, beaten egg, soy milk, juice, tea drink, corn drink, pure water, sauce, wine, cleaning solution, chemical product, sugar, grain, cornmeal, other dry powder, etc.



3. Technical parameter:



1. Capacity: 250--1000ml (can be filled by one machine)

2. Output: 800-1200 cartons/hour

3. Packing material: Cardboard carton / aluminium foil carton

4. Filling Temperature: Cold filling: 2-50 degC/ hot filling 88-92 degC

5. Cap: With capping / without capping (Optional)

6. Overall power: 23KW (three phases of electricity)

7. Size: (L*W*H): Carton forming machine: 1.3m*0.9m*1.5m

Capping machine: 0.8m*0.6m*1.2m

Filling machine: 2.0m*0.9m*2.6m

8. Compressed air pressure: 1.0-1.4 Mpa, Flow rate: 0.8-1.0M3/min, without oil, water and dust

9. Cooling water: Flow volume: Less then 20L/ min Temperature: Normal temperature

10. Net Weight: 1200kg (carton forming machine: 300kg, capping machine: 100kg, filling machine: 800kg)

11. Installation requirement: Any smooth floor, such as cement, floor tile, plastic ground, etc. Do not need to make angle.
