Introduction of Salt corrosion aging equipment:

This machine has a standardized test method to check corrosion resistence of coated samples. Salt spray test

 is an accelerated corrosion test that produces a corrosive attack to the coated samples in order to predict its

 suitability in use as a protective finish. The appearance of corrosion products (oxides) is evaluated after a

 period of time.Test duration depends on the corrosion resistance of the coating; the more corrosion resistant

 the coating is, the longer the period in testing without showing signs of corrosion. Different coatings have

different behaviour in salt spray test and consequently, test duration will differ from one type of coating to

another.



Technical Specifications of Salt corrosion aging equipment:

*Model: YSST-108

*Internal Size(mm)W×H×D: 600×400×450

*External Size(mm)W×H×D: 1250×1050×910

*Chamber Temperature Range: Ambient to +50°C,±0.5°C

*Air Temperature Range: Ambient to +63°C,±0.5°C

*Salt Manger Temperature Range: Ambient to +50°C,±0.5°C

*Saturated Air Pressure(Kg/m): 0.8 to 2.0

*Spray Volume(m/80cm/hr): 0.5 to 3.0

*Salt PH: 6.5 to 7.2

*Copper Acetate PH: 3.0 to 3.2

*Material: imported PVC & PP

*Salt Spray System: Air & acid liquid

*Heating System: SUS#304 stainless steel high-speed heater & teflon

*Controller System: Digital electronic control & S.S.R.

*Accessories:Hydrometer, salinometer, fog collector, glassbar

*Safety Devices: Overheat protector, Alarm

*Power(K.W.): AC 1Ψ 220V 60/50Hz

Main features of Salt corrosion aging equipment:

1. Detecing transparent cover is made of imported PP & PVC, which endures acid and high temperature.

2.The patented nozzle and spray unit make an uniform spray rate.

3.The defogging equipment can automatically defog, which gives us a clear view of the test samples.

Besides the Salt corrosion aging equipment, we are also manufacturing:

Temperature & humidity test Chamber, Temperature & humidity Control Host, Walk In environmental Test Room, Precision hot air Oven, Salt Spray Tester, dustproof hot Oven, Rain/Spray Test Chamber, Dust Tester,Glue dispensing machine, Air Thermal Shock Tester, Liquid Thermal Shock Tester, Temperature humidity & Vibration Combined Testing Chamber, Burn-in testing equipment, Steam Aging Tester, Electromagnetic High Frequency Vibration Tester, Tensile Tester, Drop Tester, etc.

 Customization of inner chamber size and other specification is available upon request.Welcome to enquire and purchase!
