Product Name : | JSASY-A Series Computerized High-speed Gravure Printing Machine |
| Product Origin : | China | |
| Product Category : | Printing Machines | |
| More Products : | Click here! | |
| Contact Details : | Ruian Jingsai Printing Machine Co., Ltd. | |
| Product Code : | JSASY-A Series |
Product Details
Name: JSASY-A Series Computerized High-speed Gravure Printing Machine
Maximum printing speed:120 meters /min
APPLICATION:
This machine is suit for the cellophane paper, BOPP, PET, PVC, PE, aluminum foil, paper and so on, multicolor progression printing possesses of choiceness printing performance and roll material. It is used in all kinds of top grade printing abroad.
Main Feature:
1. The whole set is in permutation and combination style, possible to add and reduce color class and add on reverse printing mechanism as required by customers.
2. Frequency conversing synchronic timing is adopted for both main machine drawing and reeling.
3. Pneumatic backpressure moving erasing knife, non-shaft pneumatic conic node printing plate loading, prompt and convenient printing plate changing.
4. Adopting control method of auto permanent tension and magnetic powder brake for unreeling.
5. Adopting pneumatic elements for control of all printing pressure roller, drawing pressure roller and open and close of oven.
6. Sealed type lengthened oven, fast drying with less energy consuming, and auto constant temperature control system.
7. Printing ink circulating system, inflatable type shaft draw in and draw out.
8. High-accuracy gear transmission box, adopting patented technique.
9. Reeling and unreeling reel by tumbling dual-station mechanism, realizing auto material change without machine halt.
10. Adopting superhard aluminum alloy guide roll after anode oxidation processing and in static balance.
11. Full automatic computer registering devices and computer still examining graphics.
wzprint2(AT)gmail(DOT)com
Main technical parameters:
Model JSASY-A800/six color
Length of printing:380-1100mm
Width of printing:800mm
Speed of printing:10-120m/min
Precision of overprint:±0.10mm
Total power:72kw
Weight of machine:22800kg
Overall dimension(L*W*H) :13000mm*2750mm*2800
